Hammer Crusher

Usage of Hammer crusher

Hammer crusher (hammer mill) are applicable for various hard and fragile materials, such as limestone, coal, salt, gypsum, alum, brick and tile, etc. The crushing compressive strength of materials should not be in excess of 150Mpa. Hammer crusher is mainly used in industries such as cement, coal separation, electricity generation, building materials and compound fertilizer, etc. And Hammer crusher can crush materials with different sizes into equal particle, which favors the next procedure. The advantages of Hammer crusher are have reliable mechanical structure, high productivity and favorable applicability.

Operating principle of Hammer crusher

The main working part of Hammer crusher is rotors with hammer. The rotors consist of main shaft, disk, pin shaft and hammers. The motor drives the rotors to rotate quickly in the crushing cavity. Raw materials enter the crusher through the feed opening and are stricken, impacted, cut and ground by the high-speed hammer to small size.

There is a screening plate under the rotor, so that materials with size smaller than the screen mesh will be screened out and others are left to be further hammered and ground until reach the standard size. The size of the final product can be adjusted by changing the screening plate. The gap between the rotors and the screening plate can also be adjusted according to different requirement.

Hammer crusher features

1. High production capacity, high crushing ratio.

2. Low power consumption, uniform particle size.

3. Simple structure, easy to operate.

4. Low investment cost, easy management.

We offer fine Hammer crusher with low price

The most versatile machine that is used to grind almost all types of materials like Spices, Foodstuffs, Chemicals, Ayurvedic Herbs, Minerals & other miscellaneous materials.

The grinding takes place between the high speed swing hammers and top/side liners. Once the particle size reduces below that of perforated / bar type screen at the bottom, it will be discharged through the hopper.

The fineness of the material can be controlled by changing the speed of rotor (hammer), content of serrations on liners, Numbers of Hammers, diameter of perforations on the screen. If your are interested in our products, please contact us at any time.

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
