Sand maker

Introduction to Sand maker

Sand maker (Sand making machine) is the equipment which makes sand artificially. It can be impact crusher or cone crusher according to the materiel condition and production requirement.

VSI sand maker provide high quality sand aggregate for expressway, high speed railway, high-rise building, municipal works, and the construction of hydroelectric dams. It is the first choice equipment for artificial sand making and the stone reshaping.

The Features & benefits of Sand maker

1) Large capacity, high output

2) Low consumption of wear parts

3) Excellent product shape

4) Hydraulic device, easy to maintain

5) Easy to install, easy to operate

6) Automatic detection, safe and reliable

7) A multifunctional, flexible

8) Lubrication, automatic maintenance

9) International Quality Assurance

Main parts of VSI Sand maker

VSI Sand making machine has 7 main components such as the feed, whirl crushing chamber, impeller experience, spindle assembly, chassis, transmission and electrical machine. Because artificial sand has more advantages than natural sand, Artificial sand maker is used and welcomed in sand making production line.

Working principle

1. Center Feeding: Raw material falls down into feed hopper, and then enters impellor through central entrance hole. It is accelerated in high-speed impellor, and then is thrown out at speed of 60-75m/s. When hitting impact plate, it is crushed. Final products come downwards though outlet.

2. Ring Feeding: Raw material falls down into feed hopper, and then through ring, it is divided into two parts by material-dividing plate. One enters into impellor through the center of material-dividing plate. The other falls down from outside of material-dividing plate. Material thrown out by impellor at speed of 60-75m/s hits material coming down from outside of material-dividing plate. In this way, material is crushed.

Technical parameters of HX Series sand maker
